Combo mini-GBIC Port 15~ 16 Status LEDs
Link/ACT
On
:
When the fiber line connected to the mini-GBIC module is installed
and connected to a network, the Link/ACT LED will lights on.
Blinking :
When the Link/ACT LED is blinking, the port is transmitting or
receiving data on the Gigabit Ethernet network.
Off
:
Fiber line or mini-GBIC module is not installed.
1000Mbps
On
:
When the 1000Mbps LED lights on, the respective port is connected
to a 1000Mbps Gigabit Ethernet network.
Off
:
When the respective port is connected to a 10Mbps Ethernet or
100Mbps Fast Ethernet network
17
