DESIGN LED 60 Strip™
©Elation Professional, Los Angeles Ca. 19 www.ElationLighting.com
Dipswitch 1 is on and dipswitch 2 is on, the red value is 255
GREEN:
Dipswitch 3 & 4 off, the green value is 0
Dipswitch 3 is on and dipswitch 4 is off, the green value is 60
Dipswitch 3 is off and dipswitch 4 is on, the green value is 125
Dipswitch 3 is on and dipswitch 4 is on, the green value is 255
BLUE:
Dipswitch 5 & 6 is off, the blue value is 0
Dipswitch 5 is on and dipswitch 6 is off, the blue value is 60
Dipswitch 5 is off and dipswitch 6 is on, the blue value is 125
Dipswitch 5 is on and dipswitch 6 is on, the blue value is 255
When dipswitch 7 is set to the “ON” position internal program will be activated. When
dipswitch 7 is in the “OFF” position dipswitches 1~6 are used to access the different
internal programs. Please see the chart below for detailed information on accessing the
internal programs: Dipswitch # 10 is OFF, Dipswitch #11 is ON, and Dipswitch #7 is ON, the
fixture will run the internal programs.
Dipswitches 1 & 7 on accesses internal program 1
Dipswitches 2 & 7 on accesses internal program 2
Dipswitches 3 & 7 on accesses internal program 3
Dipswitches 4 & 7 on accesses internal program 4
Dipswitches 5 & 7 on accesses internal program 5
Dipswitch 6 & 7 on accesses internal program 6
Dipswitch 1,2 & 7 on accesses internal program 7
Dipswitch 1,3 & 7 on accesses internal program 8
The chart below details the different speed settings available for the internal
programs when the fixture is running in manual mode. The program speed can be
adjusted using dipswitches 8 and 9:
Speed Dipswitch #8 Dipswitch #9
Slow (1.1s between scenes) OFF OFF
Medium (0.6s between scenes) ON OFF
Fast (0.2s between scenes) OFF ON
Very fast (0.1s between scenes) ON ON
