DESIGN LED 60 Strip™
©Elation Professional, Los Angeles Ca. 18 www.ElationLighting.com
8. OPERATING MODES
This fixture can run in three different DMX modes, the following pages will detail the
different operating modes as well as how to achieve the different operating modes.
DMX Settings: The chart below describes how to access the different DMX modes. The
chart below also defines the how the channel will function in the different DMX modes.
DMX
operation
mode
DIP#
11
DIP#12 LED control
Mode
LEDs
control
channels
Preset
programs
channel
Strobe
channel
Master
dimming/program
speed
63CH OFF OFF Each LED can
be run
individually
1~60 61 62 63
60CH ON OFF Each LED can
be run
individually
1~60
15CH OFF ON Every 5 LEDs
to be run in
sync
1~12 13 14 15
6CH ON ON R,G,B run by
group
1~3 4 5 6
Dipswitches 11 & 12: DMX Mode Selection, See the chart above; 63, 60, 15, or 6
channel modes.
Dipswitch 10: Sound-active operation, when dipswitch 10 is in the “ON” position the
unit will change colors when it detects an audible sound. This function work in either
stand-alone unit or master/slave modes.
Manual Settings: The chart below details the dipswitch setting for various manual settings.
Manual static colors are achieved when dipswitch 7 is in the “off” position.
Follow the dipswitch settings below to achieve various static colors by combining different
color LEDs with various intensity levels.
RED:
Dipswitch 1 & 2 off, the red value is 0
Dipswitch 1 is on and dipswitch 2 is off, the red value is 60
Dipswitch 1 is off and dipswitch 2 is on, the red value is 125
