Emerson CF759PB00 - Manual (Page 8)

8
FAN/OFF
FOR/REV
LIGHT
DIMMER
HIGH
MED
LOW
®
Figure 17
Operation of Your
Remote Control
1. To set the desired fan speed, push the HI, MED or
LOW buttons to set your fan on high, medium or
low speed. (See Figure 17).
2. To reverse the direction the fan is turning, press
the FOR/REV button. The direction the fan turns
will change each time the FOR/REV button is
pressed.
3. To turn the fan OFF press the FAN/OFF button.
4. To set the level of light brightness, press and hold
the LIGHT DIMMER button. The light brightness
will continue to increase then decrease while the
button is held down. When the light is at the
desired brightness, release the button.
5. To turn the light ON or OFF, press and release the
LIGHT DIMMER button. The light will turn ON at
the light level previously set (See Step 4).
Red light turns on when any button is pressed.
If the light does not come on, replace your
battery.
1. Restore electrical power to the outlet box by turning
the electricity on at the main fuse box.
2. Remove the battery cover by pressing firmly on the
arrow and sliding the cover off the control
transmitter.
3. Engage the connector in the transmitter with the
terminals of a 9-volt alkaline battery (not supplied)
(Figure 16).
4. Position the battery in the transmitter and replace
the battery cover.
5. Operate ceiling fan using the Remote Control
transmitter.
Using Your Ceiling Fan
9-VOLT ALKALINE
BATTERY (NOT
SUPPLIED)
REMOTE CONTROL
TRANSMITTER
BATTERY COVER
Figure 16
SWITCH
LEVERS
SWITCH
LEVERS
Figure 14. TRANSMITTER Figure 15. RECEIVER
