Battery Removal & Disposal
3
Before you start:
Your Cordless Hand Sweeper will require very little assembly. You should
remove it from the carton and familiarize yourself with all the components listed
as per the parts drawing (pg.2) This will help you in the assembly and operation
of your cordless hand sweeper.
HOW TO OPERATE YOUR CORDLESS HAND SWEEPER
NOTE: If uncertain as to how to remove your battery pack, we suggest
you take your sweeper to a reputable small appliance service
technician to have this service performed.
Follow these steps when battery removal is required.
This hand sweeper is equipped with Ni-Cd batteries and you need to dispose of them
properly. When the batteries are no longer good for use, they must be removed from
the sweeper for disposal. Do not remove the batteries for any reason other than
disposal of them. The batteries must be recycled or disposed of in accordance
with local regulations. Please consult your Yellow Pages or local recycling
center for more information.
WARNING: You must never use ordinary batteries for replacement as
these may leak and cause damage. Use only battery pack XB1707H supplied
for replacement by Euro-Pro.
1. Before using, please ensure that the cordless hand sweeper has been
initially charged for 24 hours. Your cordless sweeper will only operate
properly when the batteries are fully charged. When fully charged, your sweeper
will operate for approximately 90 minutes - dependent upon the type of use
(example - counters/tabletops or upholstery).
2. Push the On/Off switch to operate the unit. To turn off, press switch again. (Fig. 1)
NOTE: Do not operate the hand sweeper without the dust tray in place.
Removal of Battery Pack
On/Off
1. Turn unit over so that the base is facing upwards.
2. With a #1 Phillips screw diver, remove the screw securing the battery pack
compartment cover to the unit and place aside. (Fig. 9)
3. Remove the old battery pack from the unit and detach the connector jack from
the unit. (Fig. 10)
4. Attach the connector jack from the new battery pack to the female connector jack
in the battery compartment.
5. Insert the new battery pack into the battery compartment making sure that all the
wiring carefully tucked inside under the battery pack.
6. Replace screw to secure the battery compartment cover to the unit. Do not
over tighten.
CAUTION: This appliance contains Ni-Cd batteries. The batteries
must be recycled or disposed of in accordance with local regulations.
Please consult your Yellow Pages or local recycling center for more
information.
Fig. 9
Fig. 10
Fig. 1
For an extended reach this unit is equipped with a telescopic handle.
1. To extend the handle, press on the telescopic handle release button and pull
up slightly to release the locking mechanism. Continue to pull handle all the
way up until it clicks into place. (Fig. 2)
2. To store press the telescopic handle release button while pushing the handle
down to release the locking mechanism. Continue to push down on the
handle until it locks into place. You may now fold the handle down.
EXTENDING THE TELESCOPIC HANDLE
Telescopic Handle
Release Button
Fig. 2
4.8 V DC 900 mAh CAUTION: Any electronic or electrical appliance should not
be stored in or exposed to areas of high heat or humidity. Do
not store your cordless hand sweeper close to stoves,
radiators, furnaces or in a bathroom or bathing area.
6
