MDA 5V, 5SV, 5A RCA • Specifications 9
DC offset ........................................ ±50 mV with input at 0 offset
Sync
Standards ........................................ NTSC 3.58, NTSC 4.43, PAL, SECAM
Audio — MDA 5A RCA
Gain
DIP switch set to match output type .....................Unity (0dB)
DIP switch not matched to output type
Dip Switch
Setting
Output Wiring
Unbalanced
Balanced
Balanced 0 dB -6 dB
Unbalanced +6 dB 0 dB
Frequency response ..................... 20 Hz to 20 kHz, ±0.05dB
THD + Noise ................................. 0.03% @ 1 kHz at nominal level
S/N ................................................. >90 dB, unbalanced, at maximum output
Stereo channel separation ........... >80 dB @ 1 kHz; >60 dB @ 20 kHz
CMRR ............................................. >75 dB @ 20 Hz to 20 kHz
Audio input — MDA 5A RCA
Number/signal type ..................... 1 stereo unbalanced
Connectors ..................................... 2 RCA connectors
Impedance ...................................... >10 kohms unbalanced, DC coupled
Nominal levels ............................... +4 dBu (1.23V), 0 dBu (0.775V),
-10 dBV (316mV), -20 dBV (100mV)
compatible
Maximum level ............................. +17 dBu (unbalanced) at 1%THD+N
N 0 dBu = 0.775 Vrms, 0 dBV = 1 Vrms, 0 dBV 2 dBu
Audio output — MDA 5A RCA
Number/signal type ..................... 5 stereo, unbalanced
Connectors ..................................... 10 RCA connectors
Impedance ...................................... 50 ohms unbalanced
Gain error ...................................... ±0.1dB channel to channel
Maximum level (Hi-Z) ................ +15 dBu, unbalanced at 1%THD+N
Maximum level (600 ohm) ........... >+14 dBm, unbalanced, at 1%THD+N
General
External power supply ................ 100VAC to 240VAC, 50/60 Hz, 5 watts,
external; to 12 VDC, 1 A (max.), regulated
