MDA 5V, 5SV, 5A RCA • Specifications
Specifications
8
Specifications
Video
Gain ................................................ Unity
Bandwidth
Composite video ............... 400 MHz (-3dB)
S-video ................................ 270 MHz (-3dB)
Video input
Number/signal type
MDA 5SV ............................ 1 S-video
MDA 5V .............................. 1 composite video
Connectors
MDA 5SV ............................ 1 4-pin mini DIN female
MDA 5V .............................. 1 BNC female
Nominal level ................................ 1 Vp-p for Y of S-video and for composite
video
0.3 Vp-p for C of S-video
Minimum/maximum level(s) ..... 0.4 V to 2.0 Vp-p for composite video or Y
of S-video with no offset
Impedance ..................................... 75 ohms
Return loss
MDA 5SV ........................... <-25dB @ 0 to 10 MHz
MDA 5V .............................. <-27dB @ 5 MHz
DC offset (max. allowable)........... 5.0V
Input coupling ............................... AC
Video output
Number/signal type
MDA 5SV ............................ 6 S-video: 5 buffered for distribution, 1
passive loop-through
MDA 5V .............................. 6 composite video: 5 buffered for
distribution, 1 passive loop-through
Connectors
MDA 5SV ............................ (6) 4-pin mini-DIN
MDA 5V .............................. 6 BNC female
Nominal level ................................ 1 Vp-p for Y of S-video and for composite
video
0.3 Vp-p for C of S-video
Minimum/maximum level(s) ..... 0.4V to 2.0V p-p, follows input
Impedance ..................................... 75 ohms
Return loss ..................................... <-30dB @ 5 MHz
