Electrolux E30GC74GPS - Manual

30" GAS SLIDE-IN COOKTOP
Configuration
FEATURES
Formed Stainless Steel Platform
Large Professional Skirted Knobs with Bezel
Min-2-Max
™ Dual-Ring Sealed Burner (BTU)
Sealed Power Burner ™ (BTU)
Sealed Precision Burner ™ (BTU)
Linear Flow Burner Valves
Electronic Ignition with Auto Re-Ignition
Continuous Grates
ACCESSORIES
Griddle
Wok Ring
Simmer Plate
9" Stainless Steel Backsplash – PN # 903048-9100
Black Knobs Kit – PN # 903049-9110
Depth Adjustment Filler Kit * – PN # 903051-9100
SPECIFICATIONS
Overall Exterior Dimensions –
Height
Width
Depth
Gas Inlet / Power Supply Location
LP Gas Conversion Kit
Voltage Rating
Connected Load (kW Rating) @ 120 Volts
‡
Electrical Cable
Approved for Single Oven Combination Installation**
Approved for Downdraft Vent Combination Installation**
Shipping Weight (Approx.)
* When replacing an existing cooktop with countertop cutout deeper than 7-1/4"
and less than 8-1/2", order free Depth Adjustment Filler Kit.
‡ For use on adequately wired 120V, dedicated circuit having 2-wire service with
a separate ground wire. Appliance must be grounded for safe operation.
** Not approved to be used over any Electrolux ICON ® Single Wall Oven. Approved to be
used in combination with an Electrolux ICON ® Downdraft Vent. (Proper combination
installation will require cooktop power cord to be relocated.)
NOTE: Always consult local and / or national electric and gas codes. Refer to Product
Installation Guide for detailed installation instructions on the web at electroluxicon.com.
Specifications subject to change.
4 Sealed Burners
Yes
4
2 (18,000 – 450)
1 (14,000)
1 (5,000)
4
Yes
3
Included
Included
Included
Optional
Optional
Optional
7-3/4"
29-7/8"
25"
Right Rear
Included
120V / 60 Hz /15A
0.001
Included
No
Yes
100 Lbs.
electroluxicon.com
Min-2-Max ™ Burners
Burner configuration includes two versatile
Min-2-Max
™ sealed burners delivering anywhere
from 18,000 to 450 BTUs. Thanks to the double
ring configuration, you can simmer sauces or
bring water to a boil. You decide the level of heat
output by a simple turn of the knob.
Four Sealed Burners
Versatile sealed burner configuration provides
the utmost in cooking flexibility. Includes: two
18,000 - 450 BTU Min-2-Max
™ burners, one
14,000 BTU Power Burner ™ and one 5,000 BTU
Precision Burner ™ .
Sealed Cooktop Spill-Basin
Cleanup is convenient with a black porcelain-
coated area beneath the burners to catch spills.
Professional-Style Controls
Large professional-feel, front-mounted control
knobs provide easy and accurate settings. 270
degree rotation offers superior flame control.
Optional black knobs available.
Designed for the well-lived home.
Gas Slide-In Cooktop
E30GC74GPS
