Using the Cleaning Tools
Changing and Cleaning the Filter
1. Crevice Tool
For radiators, crevices, corners,
baseboards and between cushions.
• Filter should be cleaned at least twice a year or when it becomes visible solid.
• Always operate the cleaner with the filter installed.
• Disconnect from electrical outlet before cleaning the filter.
• Do not use a washing machine to rinse the filter.
• Do not use a hair dryer to dry it.
2. Dusting Brush
The dusting brush is used for the
furniture, venetian blinds, books, lamp
shades and shelves.
Deluxe Air Driven Turbo Brush (Optional)
The Deluxe Air Driven Turbo Brush is a deluxe floor attachment with a rotating
brush turned by the air flow of the vacuum cleaner. The Turbo Brush is used
for cleaning high pile carpets or whenever agitation of the carpet fibers is
required. The Turbo Brush should NOT be used on hard floors.
Fig. 1 Fig. 2
Slide Slide
For high pile carpet For low nap carpet
• Turn off the vacuum and unplug from wall outlet.
• Attach the Deluxe Air Driven Turbo Brush to the telescopic tube.
• Re-plug the vacuum into the wall outlet and start the vacuum. Beater bar on
the Air Driven Turbo Brush will begin to rotate and will continue to operate
as long as the vacuum is “ON”.
• The Air Driven Turbo Brush is adjustable for carpet nap. To adjust for high
pile carpet, move the slide control on top of the brush housing as shown in
Fig. 1.
• For low nap adjust the slide control as shown in fig. 2.
1. Push the dust cup lock to
open the dust cup.
2. Remove the filter from the
grill-filter.
3. Rinse filter in lukewarm
water and dry the
filter completely.
4. Put the filter into the grill-filter.
5. A severely solid or clogged filter
should be thoroughly washed
with fresh tepid water. A mild
detergent can be used if
required.
Using the Deluxe Air Driven Turbo Brush (Optional)
WARNING: The beater brush of this floor attachment rotates very fast.
To avoid injury,
DO NOT TOUCH the beater brush with fingers while the
brush is rotating.
