15
RF 1000 [BCD-280W/H(E)]
No Part name Part number Pieces Remark
1 Upper hinge cover 9210200294 1 BCD280W/H(E).00-03
2 Flange screw M5x20 1701184 6 M5 x20 BDG36-20
3 Upper hinge parts 9120400231 1 BCD280W/H(E).00.01-00
4 Cabinet 9100100296 1 BCD280W/H(E).08-00
5
Air return cover of freezer
chamber
9210200302 1 BCD280W/H(E).00-04
6 High front leg 11041 1 TB00.04-00
7 Evaporator 9130100212 1 BCD280W/H(E).02-00
8
Anti-explosion heating tube for
defrosting
140499 1 BDG22-44
9 water trough 9110600117 1 BCD280W/H(E).08.03-04
10 Reflecting aluminum foil 9260100157 1 BCD280W/H(E).04-04
11
Wind channel foam of freezer
chamber
9101200198 1 BCD280W/H(E).04-02
12 Mid-Hinge bottom plate 1107448 1 BCD168W.00-15
13 Mid-hinge 9120400233 1 BCD280W/H(E).00-07
14 Flange screw M5x30 1701164 2 M5 x30 BDG36-14
15 Lamp switch 1410108 1 60B(BDG16-32)
16 Mid-hinge hole cover 9210200301 5 BCD280W/H(E).00-09
17 Screw cap 17011 1 T00-16
18
Anti-explosion lamp holder
assembly
141248 1 BDG17-39
19 Bulb 141239 1 AC115V/60Hz 10W
20 Temperature control 1401131 1 NWPF4K-089-100
21 Lower hinge assembly 9120400234 1 BCD280W/H(E).00.06-00
22 Short front leg 11042 1 TB00.01-00
23 Temperature fuse unit assembly 1411297 1 BDG18-16
