EverFocus Megapixel Over Coax Without Networking EQH5000 - Manual (Page 3)

EPHD08
100% HD
8 Channel HD
EDR-HD-2H14
Hybrid
2 HD Ch / 14 Analog
EDR-HD-4H4
Hybrid
4 HD Ch / 4 Analog
Total Camera Inputs 8 16 8
Supported Formats
Global All Ports
1080i60/50, 1080p30/25, 720p60/50
Mix & Match Ports
1080i60/50, 1080p30/25, 720p60/50, 720p30/25
HDcctv Camera Inputs 8 BNC 2 BNC 4 BNC
Analog Camera Inputs N/A 14 BNC 4 BNC
Looping Analog Cam Outputs N/A 14 BNC 4 BNC
Total HD
Recording
Rate
1080 120 FPS NTSC | 100 FPS PAL 30 FPS NTSC | 25 FPS PAL 60 FPS NTSC | 50 FPS PAL
or 720 240 FPS NTSC | 200 FPS PAL 60 FPS NTSC | 50 FPS PAL 120 FPS NTSC | 100 FPS PAL
D1 N/A 420 FPS NTSC | 400 FPS PAL 120 FPS NTSC | 100 FPS PAL
Pentaplex Operation Simulatneous Live, Recording, Playback, Archive and Remote Viewing
Video Ouput Main Monitor 1080p HDMI Socket | VGA: 1920 x 1080 @ 60Hz
External HDD Support 1 eSATA
Audio 8 Inputs / 1 Output 16 Inputs / 2 Outputs 8 Inputs / 2 Outputs
Recording Mode Manual, Schedule, Event
Playback Search Date/Time, Event, Motion, Smart Date/Time, Event, Motion, Smart, Snapshot
Alarm In/Out
8 Alarm Inputs
2 Alarm Outputs
Form “C” rated at 30VDC, 1A
16 Alarm Inputs
4 Alarm Outputs
Form “C” rated at 30VDC, 1A
8 Alarm Inputs
4 Alarm Outputs
Form “C” rated at 30VDC, 1A
OS/Interface Embedded Linux with Graphical User Interface
Network Gigabit Ethernet + FREE DDNS from EverFocus
USB (3) USB 2.0 Port (2) USB 2.0 Ports
DVD Burner Built-in DVD Burner
User Access 3 Levels of User Access
RS-485
1 RS485
(3 Terminal Connector)
RS485
(2 RJ45 Connector)
PTZ Protocols EverFocus, Pelco-P, Pelco-D, Samsung, Transparent
Power Source 100VAC ~ 240VAC
Power Consumption 130 W Max with 4x HDDs 100 W. Max with 4 x HDDs
Dimensions 16.2” x 16.9” x 3.5” 16.6” x 16.9” x 3.2”
Operating Temp 32° ~ 104° F
HDcctv DVR Features *
• 1080/2 Megapixel or 720/1 Megapixel
• Up to 8 Channels of Superior HDcctv
Recording & Viewing
• 1.5 Gb/s Digital Megapixel Video Over Coax
• Up-to 16x Zoom on Local & Remote Live & Playback
• Dual Streaming: View remotely with reduced or full
resolution bandwidth while recording full 1080/720
• HDMI & VGA Main Monitor Outputs
H
igh
D
efinition
1080
Camera Resolution Captures
Incredible
Detail
HD Features: Choice of HDcctv Resolution: 1080/2-Megapixel (1920 x 1080) or 720/1-Megapixel (1280 x 720)
SD TV Output for Easy Camera Installation and Focus
• iPhone/Blackberry/Android with free remote viewing app
• Network Ready, FREE DDNS
• Up to 8 TB of Internal Storage Plus 2-8 TB of External eSata Storage
• Easy to use Graphical User Interface
• Smart Search Functions (Motion/Snapshot)
• Simultaneous Pentaplex Operation
Simultaneous Live/Record/Playback/Archive/Remote
• DVD Burner Plus Multiple USB Ports
• Express Setup/Archive/Playback/Search
• PTZ Control (On-Screen & Over Network)
• Per-Camera Audio Channels
• Rack Mountable: Rack Ears Included
• IR Remote & USB Mouse Included
* Select features may vary with DVR model
EDR-HD-2H14
EPHD08
