2-16

E l o E n t u i t i v e T o u c h m o n i t o r U s e r G u i d e

Mounting the Base

You can also mount your touchmonitor by using the keyholes in the base of the
stand. These keyholes provide easy slide on mounting. You can also bolt your
touchmonitor to a tabletop or other flat surface. Please refer to Appendix C for
location and dimension of the mounting holes.

M5 screw (4X)

M5 washer (4X)
