Touchmonitor connections (serial and usb) – Elo TouchSystems 1925L Series User Manual
Page 11
2-7
Figure 2.2
Touchmonitor Connections (Serial and USB)
The following table indicates the LED status options for the Touch LED.
N
OTE
:
Touch LED is currently only available with IntelliTouch -Serial Option monitors.
USB Option
USB In and Touch Screen Connector
USB Out
Serial Option
AC Power
DC Power
Audio In, PC Sound Card
Video In, RCA Jack
Audio In, RCA Jack
S-Video
DVI-I, including Analog
Touch LED Status
Serial Touchscreen
Connector
Power LED status
LED Status On
LED Status Off
LED Status Blinking
Contact Elo Support
Contact Elo Support
OK
