Electrical connection

WARNING

This appliance falls under Protection Class I.

The earth wire (green/yellow wire) must be connected to the point
marked

.

Switch the electrical circuit off and secure it against unintentional reactivation.

Unscrew the four screws at the rear of the connection box and remove the
cover.

First, pull a cable through the cable entry

9

into the connection box and

secure it to the available cable strain relief.

Connect the cable to the terminals, as shown in the connection diagram.

Replace the cover of the connection box and screw it down fi rmly.

Now switch the power supply back on.

N

L

X

Brown or black wire (L)
Blue wire (N)
Green/yellow wire ( )

Fig. Terminal diagram
