26 GB
Preparing the product for use / Care and cleaning
Preparing the product for use
Assembling the lamp
Note: You will require a second person to help
with the assembly of the product.
Note: Assembly is identical for both models
(1241 / 022L or 1242 / 022L).
Before installation, remove the two black plastic
rings on the end of the support tube 18 to allow
the components to be screwed together properly.
First screw the support tube 18 clockwise into
the upper support tube 21 . Ensure that the
mains lead does not become trapped when it
is fed through the support tubes
18 , 21 .
Then screw the support tube 10 clockwise into
the flexible arm 5 .
Screw the two threaded rods 17 clockwise into
the support tubes 10 , 18 and push the support
tube mount 16 on to the threaded rods 17 .
Insert the floor lamp with the threaded rods 17
into the preformed holes in the base 13 .
Place the serrated lock washers 14 at the
underside of the support tube 13 on to the
threaded rods 17 . Using the open spanner,
tighten the nuts 15 clockwise on to the threaded
rods 17 to fix the floor lamp to the base 13 .
Note: Ensure that you hold the support tubes
10 , 18 and threaded rods 17 firmly in place
when you are tightening the nuts 15 .
Note: Ensure that the threaded rods 17 are
screwed in as far as possible so that the lamp
is stable when standing up.
Push the lamp glasses 3 , 7 over the fittings
4 , 6 . Fix the lamp glasses in place with the
threaded rings 2 , 8 using the tool 9 .
Note: Use a dry, fluff-free cloth for inserting
the bulbs.
Screw the bulbs 1 , 11 clockwise into the
fittings 4 , 6 .
Insert the mains plug 12 into a properly
installed socket.
Your lamp is now ready for operation.
Switching the lamp on / off
Use the ON / OFF switch 20 to switch the
uplight on or off.
Use the ON / OFF switch 19 to switch the
reading lamp on or off.
Directing the lamp
Bend the flexible arm 5 to bring the reading
lamp into the desired position.
Replacing a bulb
RISK OF ELECTRIC SHOCK!
First pull the mains plug 12 out of the mains socket.
CAUTION! RISK OF BURNS! First allow the
lamp to cool completely.
Unscrew the defective bulb 1 , 11 anticlockwise
out of the fitting 4 , 6 .
Then screw a new bulb clockwise into the fitting.
Note: Use only 230–240 volt ∼ energy-saving
bulbs with an E14 fitting and a maximum power
output of 9 watts for the reading lamp. Use
only 230–240 volt ∼ energy-saving bulbs with
an E27 fitting and a maximum power output of
22 watts for the uplight.
or
Use only 230–240 volt ∼ bulbs with an E14
fitting and a maximum power output of 25 watts
for the reading lamp. Use only 230–240 volt ∼
bulbs with an E27 fitting and a maximum power
output of 60 watts for the uplight.
Care and cleaning
RISK OF ELECTRIC SHOCK!
First pull the mains plug 12 out of the mains socket.
CAUTION! RISK OF BURNS! First allow the
lamp to cool completely.
RISK OF ELECTRIC SHOCK!
For electrical safety reasons, never clean the lamp
with water or other fluids nor immerse it in water.
