13 GB/IE
nails or clamps, to fasten the
product in place.
Avoid bending the product.
Otherwise the insulation could
be damaged.
Installation
The LED strip light 1 can be con-
nected using a connection cable
2 (Fig. B) or without a connection
cable (Fig. C).
Mounting the product
on a cupboard
Note: Thoroughly clean the surface
on to which you intend to install the
product. The surface must be clean,
dry and free of grease. Otherwise
the self-adhesive foil may not stick
properly.
1. Using a pencil, mark the position
on the wall on to which you
intend to attach the LED light
strip
1 . If necessary, use a
spirit level as a guide.
2. Stick the double-sided adhesive
tape onto the LED light strip 1 .
Then pull the paper from the
self- adhesive foil on the back of
the LED light strip
1 .
3. Position the self-adhesive foil on
the markings and press to fix it
firmly into place (Fig. D).
