11 GB/IE
Batteries must not be disposed
of in the normal domestic waste!
All end users are legally re-
quired to dispose of batteries
properly.
Mounting (see Fig. A)
Note: Clean the surface well
onto which you wish to mount the
product. The surface must be clean,
free from grease and dry. Other-
wise the stickiness of the double-
sided adhesive tape
5 might be
limited.
Note: Before use, check on a
hidden area of the surface, whether
the adhesive can cause damage.
Note: you will need a drill for
installation.
CAUTION! RISK OF
INJURY! Please refer to the
operating instructions of your drill.
CAUTION! Be sure not to
damage lines inside the wall.
Remove the protective film from
the adhesive on the back of
the light strips
3 and attach
the LED strip at the desired point.
Attach the LED driver 6
using the included double-
sided adhesive tape
5 or
the included screws 9 .
Connect the adaptor 4 to
the LED driver and the LED strip.
Note: Ensure when connect-
ing the LED driver
6 with the
LED strip that you align the
+GRB markings on the LED
driver with the +GRB marking
of LED strip.
Please ensure that the adaptor
4 is always accessible.
Insert the adaptor 4 into the
mains socket before you turn
on the product.
Connecting the 2 LED strips
(see Fig B):
Note: A maximum of two 5 m
LED strips can be connected with
the eight point plug
10 and oper-
ated with one LED driver and one
adaptor
4 . Otherwise there is
the risk of overloading the compo-
nents and fire.
Note: Ensure when connecting
the ends of the LED strip using the
eight point plug that you align the
