14 GB
Installation / Cleaning / Disposal / Warranty and Service Safety information / Preparation / Installation
Risk of burns and injury!
Do not install the light, if it has a defective lamp
glass. In this case contact the service centre for
a replacement.
Only install the light on normally inflammable
or non-inflammable surfaces. Excessive heat
can result in a fire.
To prevent burns, ensure that the light is switched
off and has cooled down before touching it.
Light bulbs develop a great deal of heat.
Allow the light to cool down completely before
replacing a defective bulb.
Do not attach the light to a damp or conductive
substrate.
Replace defective bulbs with new ones immedi-
ately. Use only those bulbs as stated in the
chapter on “Technical Data”. Before changing
bulbs, always first remove the fuse or switch off
the circuit breaker.
The type of bulb included is not suitable for
dimmer or electronic switches.
Only use the individual parts supplied, other-
wise all warranty claims will become invalid.
For your safety
Only use 230-240 V ∼ bulbs with a GU10
socket and a maximum output of 5 watt.
The outdoor light is splash-proof.
Always be attentive when working! Always
pay attention to what you are doing and act
with common sense. Never install the light if
you are having difficulty concentrating or do
not feel well.
Preparation
Required tools and material
The tools and materials specified are not included.
This information and these values are non-binding
and they are only for guidance. The nature of the
material is determined by the individual local con-
ditions.
– Pencil /marking tool
– Voltage tester
– Cross-tip screwdriver
– Electric drill
– Edge cutter
– Allen hexagon key 8 mm
Prior to installation
Important: Ensure that a qualified electrician, or
a person trained to carry out electrical installations,
performs the electrical installation.
Familiarise yourself with all the instructions and
diagrams in this manual, as well as with the
light itself, before you install it.
Before installation ensure that the circuit, to
which the light will be connected, is not ener-
gised. To do this, remove the fuse or switch off
the circuit breaker in the fuse box (0 setting).
Use the voltage tester to verify the de-ener-
gised status.
Installation
Unscrew the lamp glass 1 from the light
body 2 .
Remove the nuts 3 , which are visible at the front
of the wall plate 4 , and open the connection
housing 5 , see fig. A.
Use the holes in the connection housing 5 ,
which are intended for the screws, to mark the
drill holes. Open these holes (if they are not
open) with a pointed object (e.g. screwdriver).
Ensure that that you fasten the connection
housing with the arrow facing upwards (on the
rear of the connection housing).
Now drill the fixing holes (ø approx. 6 mm,
depth approx. 40 mm). Ensure that you do not
damage the electrical supply line.
Now introduce the wall plugs into the drill holes.
