7
Assembly / Electrical connection
LESB 22 A1
GB
Assembly
WARNING
When drilling, take care not to damage any pipes/cables in the wall or ►
ceiling.
The supplied plugs are only suitable for a mounting on concrete or stone.
►
Before starting the installation, please check your installation location care-
fully for its suitability for the plugs. If in doubt, call a professional.
NOTICE
For easier installation the bracket ► 5 can be unscrewed from the appliance.
Drill two holes with a diameter of 6 mm and a depth of 30 mm at a spacing ♦
of 68 mm.
Insert a plug into each of the holes and screw the appliance with the ♦
bracket 5 to the ceiling or wall (see Fig Ceiling mounting/Wall mounting).
Fig. Wall assembly Fig. Ceiling assembly
