Note: Use the flat surface for easy
insert. The stick can be turned inside
the clip for angle adjustment.
Cupboard mounting
(Fig. A–D):
Install the attachment clips in the
desired position with the screws
(see Fig. A).
Attach the light strip to the
attachment clips (see Fig. B).
Wall mounting
(Fig. E–H):
Drill the fastening holes in the wall.
CAUTION! Ensure that you do
not damage any cables in the wall.
Insert the dowels into the drilled
holes (see Fig. E).
Fix the attachment clips to the
wall with the screws (see Fig. E).
Attach the light strip to the
attachment clips (see Fig. F + G).
Use
Insert the plug of the switch into
the socket of the mains adapter
(see. Fig. D + H).
Plug the mains plug into the
socket (see Fig. I).
Use the ON- / OFF-switch (sup-
ply lead) and the press switch
(light strip) to switch on the light
strip (see Fig. D + H).
To switch off, pull the mains
plug out of the mains socket or
