M SUBWOOFER SPECIFICATIONS
This product is not magnetically shielded, so avoid placing it in proximity to a CRT television or
computer monitor screen
Amplifier type Class D, high efficiency switching circuit
Amplifier power output 300 Watts into 4 Ohm load continuous
Frequency response of 20Hz to 150Hz with high and low filter settings at
system max and min
Speaker impedance 4 Ohms
Sensitivity 89dB per Watt
Maximum system output SPL 112 dB at 1 metre for music program
Amplifier capability 300 Watts into 4 Ohms continuous / 500 Watts peak
Bass driver 10" (254mm) steel chassis with reinforced paper cone
and inverted dust cover. 3" (75mm) high temperature
voice coil wound on an aluminium former with high
power ceramic magnet system.
Filter compensation circuit Multi-element, high and low-pass filters with
adjustable phase and active gain control
Cabinet Real cherry wood finish, 25mm MDF carcass with
internal cross bracing to form a very rigid and sonically
dead structure. Double thickness baffle and separate
back panel to house the amplifier in its own independent
cavity
Finishes Light Cherry, Dark Cherry Black (Black painted plinth)
Dimensions H x W x D mm 372 x 342 x 450 including plinth
Weight 26Kgs/57lbs
