EPOS M Series - Manual

M SERIES SUBWOOFER
OPERATING INSTRUCTIONS
Thank you for purchasing this Epos M series subwoofer.
The following items are supplied with your subwoofer - should any item be missing please contact
your dealer:
Plinth with 6mm carpet spikes (4) and metal discs (4)
Fixing bolts - long - Type A - (4)
Fixing bolts - short - Type B - (4)
Felt pads (4)
Feet (4)
Power cables (see text in warning section)
WARNING
For safety reasons please read the following instructions carefully before attempting to connect
your Epos M subwoofer to the mains.
The M subwoofer is not designed for permanent external use. Being a powered product it would
be damaged by rain water or other contaminants entering into the amplifier via the vent holes and
the wooden cabinet would be damaged if soaked with water.
As with all electrical products, make sure the correct mains voltage is selected by the two way
selector switch on the rear panel marked AC Voltage Selector. If you are in any doubt, contact your
supplier for advice. As a general rule, the amplifier cannot be damaged by supplying lower
voltages than marked on the switch panel, but excessive voltage will cause the mains fuse to blow
or possibly even damage the internal circuitry (if in doubt, ask your dealer/supplier).
Two power cords are supplied as standard with the M subwoofer. These have the international
IEC connector for plugging into the amplifier panel at one end and either of two styles of plug at
the other end.
USA, Canada and Japan
The USA style plug with two flat blades should be used with the voltage selector switched to 115V
operation and a mains fuse rated at 4 Amp inserted in the pull-out drawer.
Europe
The two round pin Euro plug should be used with the AC Voltage selector switched to 230V.
Rest of World
Your distributor/dealer will ensure you have the correct cable. Please check if in doubt.
