14 GB/MT
Installation / Cleaning and Care / Disposal Preparation / Installation
Prior to installation
Important: Ensure that a qualified electrician, or
a person trained to carry out electrical installations,
performs the electrical installation.
Familiarise yourself with all the instructions and
diagrams in this manual, as well as with the light
itself, before you install it.
Before installation ensure that the circuit, to which
the light will be connected, is not energised. To
do this, remove the fuse or switch off the circuit
breaker in the fuse box 0 position.
Use the voltage tester to verify the de-energised
status.
Installation
3433-025L and 3435-024L:
Unscrew the light body 2 from the connection
housing 1 by loosening the screws 3 coun-
ter-clockwise (Fig. A).
3434-024L:
Unscrew the cover 11 from the connection
housing 1 by loosening the screws 12 coun-
ter-clockwise (Fig A).
Unscrew the lamp shade 10 from the connec-
tion housing 1 by loosening the screws 13
counter-clockwise.
3433-025L, 3434-024L and 3435-024L:
Use the holes in the connection housing 1 ,
which are intended for the screws, to mark the
drill holes.
Now drill the fixing holes (ø approx. 6 mm, depth
approx. 40 mm). Be careful not to damage the
supply line.
Now insert the rawlplugs 4 into the drill holes.
Open the membrane for the mains connection
lead 6 with a thorn or a sharp knife.
Insert the mains connection lead 6 through the
membrane.
Fasten the connection housing 1 with the screws
included in delivery 5 .
Pull the protective tube 8 over the mains con-
nection lead 6 .
Connect the connection cable of the light to
the power cord 6 using the terminal block 7
(Fig. C).
Also ensure that the colour connection of the
wires is correct when connecting (L or 2 = black
or brown, N or 1 = blue).
Now connect the earth wire (3 = green-yellow)
to the marked earth terminal (see Fig. C).
3435-024L:
Use a clean, lint-free cloth to insert the lamp.
Carefully insert the lamp
14 E14, 5.5 W, into
the socket and tighten clockwise (Fig. B).
3433-025L and 3435-024L:
Screw the light body 2 to the connection
housing 1 again by tightening the screws 3
clockwise (Fig. D). Ensure the rubber seals 9
are positioned correctly.
3434-024L:
Screw the lamp shade 10 to the connection
housing 1 by tightening the screws 13 clock-
wise.
Ensure the rubber seals 9 are positioned
correctly.
Screw the cover 11 to the lamp shade 10 by
tightening the screws 12 clockwise (Fig. D).
3433-025L, 3434-024L and 3435-024L:
Check for correct fitting.
Your light is now ready for use (Fig. E).
Reinsert the fuse or switch the circuit breaker
back on.
3436-025L:
Unscrew the light body 2 from the connection
housing 1 by loosening the screws 3 coun-
ter-clockwise (Fig. A).
Use the holes in the connection housing 1 , which
are intended for the screws, to mark the drill holes.
Ensure that that you fasten the connection hous-
ing
1 with the arrow facing upwards (on the
rear of the connection housing).
Now drill the fixing holes (ø approx. 6 mm,
depth approx. 40 mm). Be careful not to dam-
age the supply line.
Now insert the rawlplugs 4 into the drill holes.
