4 GB
LED Spotlight
Intended use
The LED spotlight with motion
detector is intended for automatic
lighting in outdoor areas. This device
is solely intended for private use.
Parts description
1 Spot
2 Connection box
3 Cable gland
4 Mounting stirrup
5 Hinge joint
6 Locking screw (motion detector)
7 Motion detector
8 Rotary control SENS (sensitivity)
9 Rotary control TIME
(switched on duration)
10 Rotary control LUX
(light sensitivity)
11 Terminal block
Technical Data
Operating voltage: 230 V∼ 50 Hz,
max. 8.5 W
LEDs: 12 x LED x
3.27 V ,
0.5 W (LEDs
non-replace-
able)
Dimming switch: Adjustable
from 10 lx–
20,000 lx
Light on time: adjustable
between
approx.10 s –
4 min
Protection class: / II
Protection class: IP44 (splash
water proof)
Dimensions
(HxWxD):
approx. 197 x
149 x 120 mm
Weight: approx. 675 g
Model no.: Z31710A
(black),
Z31710B
(white)
