25735-0-0309 Page 6
Attention: During initial use of log you will detect an odor as the log
is cured.
Notice: During initial firing of this unit, its paint will bake out, and smoke
will occur. To prevent triggering of smoke alarms, ventilate the room in
which the unit is installed.
wArNING: This appliance is for installation only in a solid-fuel
burning masonry or UL 127 factory-built fireplace or in a listed
ventless firebox enclosure. It has been design certified for these
installations. Exception: DO NOT install this appliance in a factory-
built fireplace that includes instructions stating it has not been tested
or should not be used with unvented gas logs.
WARNING: Any modification to this unvented gas heater or its
controls can be dangerous. Improper installation or use of the
heater can cause serious injury or death from fire, burns, explosion
or carbon monoxide poisoning.
well Head Gas Installations
Some natural gas utilities use "well head" gas. This may affect the Btu output
of the unit. Contact the gas company for the heating value. Contact the
manufacturer or your gas company before changing spud/orifice size.
IMPOrTANT: read all instructions carefully before starting
installation. Failure to follow these installation instructions may result
in a possible fire hazard and will void the warranty.
Save this manual for future reference.
Please read this manual before installing and using the appliance.
Instructions to Installer
1. Installer must leave instruction manual with owner after installation.
2. Installer must have owner fill out and mail warranty card supplied with
unvented room heater/vented decorative appliance.
3. Installer should show owner how to start and operate unvented room
heater/vented decorative appliance.
Always consult your local Building Department regarding regulations,
codes or ordinances which apply to the installation of an unvented room
heater/vented decorative appliance.
This appliance may be installed in an aftermarket* manufactured (mobile)
home, where not prohibited by state or local codes.
*Aftermarket: Completion of sale, not for purpose of resale, from the
manufacturer.
This appliance is only for use with the type of gas indicated on the rating
plate. This appliance is not convertible for use with other gases.
New Installation
VFSV Model - variable does not operate-ON is OFF/OFF is ON-wires
into the back of receiver are reversed.
Solid-fuels shall not be burned in a fireplace where a vented decorative
appliance is installed.
A vented decorative appliance must be installed only in a solid-fuel
burning fireplace with a working flue and constructed of non-combustible
material.
Any alteration of the original design, installed other than as shown in
these instructions or use with a type of gas not shown on the rating plate
is the responsibility of the person and company making the change.
Important
All correspondence should refer to complete Model Number, Serial Number
and type of gas.
BTuH BTuH BTuH
Model Gas Valve Type Max. Rate Med. Rate Min. Rate
VFSV-16 Natural Variable 25,000 — 17,500
VFSV-16 Propane Variable 22,500 — 15,750
VFSR-16 Natural Millivolt 25,000 — 17,500
VFSR-16 Propane Millivolt 22,500 — 15,750
VFSV-18 Natural Variable 32,000 — 19,000
VFSV-18 Propane Variable 32,000 — 19,000
VFSR-18 Natural Millivolt 32,000 — 22,000
VFSR-18 Propane Millivolt 32,000 — 22,000
VFSM-18 Natural Manual 32,000 27,000 22,000
VFSM-18 Propane Manual 32,000 27,000 22,000
VFSV-24 Natural Variable 36,000 — 20,000
VFSV-24 Propane Variable 36,000 — 20,000
VFSR-24 Natural Millivolt 36,000 — 25,000
VFSR-24 Propane Millivolt 36,000 — 25,000
VFSM-24 Natural Manual 36,000 27,000 22,000
VFSM-24 Propane Manual 36,000 27,000 22,000
VFSV-30 Natural Variable 38,000 — 20,000
VFSV-30 Propane Variable 38,000 — 20,000
VFSR-30 Natural Millivolt 38,000 — 26,000
VFSR-30 Propane Millivolt 38,000 — 26,000
VFSM-30 Natural Manual 38,000 27,000 22,000
VFSM-30 Propane Manual 38,000 27,000 22,000
PrODucT SPecIFIcATION
AcceSSOrIeS
Description Color
For use with VFSV, VFSM and VFSr models
EK-1
Embers Kit
ELH-1 Fireplace Hood for Vent-Free Logs Black
ELH-2 Fireplace Hood for Vent-Free Logs Brass
For use with VFSr models only
FRBC
Battery Operated Remote Control
FRBTC Battery Operated Remote Control with Thermostat
FREC Electric Remote Control
FWS Wall Switch
TMV Wall Thermostat, Millivolt - Reed Switch
INTrODucTION
Natural Gas Propane Gas
Variable Millivolt Manual Variable Millivolt Manual
Regulator pressure setting 3.5" W.C. 3.5" W.C. 6.0" W.C. 10.0" W.C. 10.0" W.C. 10.0" W.C.
Gas inlet pressure Max. 10.5" W.C. 10.5" W.C. 10.5" W.C. 13.0" W.C. 13.0" W.C. 13.0" W.C.
Min. 5.0" W.C. 5.0" W.C. 7.0" W.C. 11.0" W.C. 11.0" W.C. 11.0" W.C.
