25735-0-0309 Page 21
Attention: When ordering parts, it is very important that part number and description of part coincide.
USE ONLY MANUFACTURER'S REPLACEMENT PARTS. USE OF ANY OTHER PARTS COULD CAUSE INjURY OR DEATH.
Index
No.
Part
No.
Description
cOMMON PArTS
1 15425 REAR LOG SUPPORT (VFS(M,R,V)-16)
1 15426 REAR LOG SUPPORT (VFS(M,R,V)-18)
1 15427 REAR LOG SUPPORT (VFS(M,R,V)-24)
1 15428 REAR LOG SUPPORT (VFS(M,R,V)-30)
2 11285 BURNER SUPPORT - LEFT (VFS(M,R,V)-16)
2 11376 BURNER SUPPORT - LEFT (VFS(M,R,V)-(18,24,30))
3 P-200 ORIFICE FITTING
4 P-204 ORIFICE - LP (VFS(R,V)-16)
4 P-256 ORIFICE - NAT (VFS(R,V)-16)
4 P-250 ORIFICE - LP (VFS(M,R,V)-18)
4 P-203 ORIFICE - NAT (VFSM-18)
4 P-243 ORIFICE - NAT (VFS(R,V)-18)
4 P-245 ORIFICE - LP (VFS(M,R,V)-24)
4 P-244 ORIFICE - NAT (VFS(M,R,V)-24)
4 P-265 ORIFICE - LP (VFS(M,R,V)-30)
4 P-209 ORIFICE - NAT (VFSM-30)
4 P-211 ORIFICE - NAT (VFS(R,V)-30)
5 R-5676 AIR SHUTTER - NAT
5 R-5675 AIR SHUTTER - LP
7 11833 PILOT SHIELD (NAT ONLY)
9 12347 BURNER ASSEMBLY (VFS(M,R,V)-16) NAT
9 12348 BURNER ASSEMBLY (VFS(M,R,V)-16) LPG
9 14033 BURNER ASSEMBLY (VFS(M,R,V)-18)
9 14035 BURNER ASSEMBLY (VFS(M,R,V) -24)
9 14037 BURNER ASSEMBLY (VFS(M,R,V)-30)
NS 12389 CERAMIC MEDIA
NS 15998 ROCK WOOL (VFS(M,R,V)-16)
NS 15999 ROCK WOOL (VFS(M,R,V)-18)
NS 15970 ROCK WOOL (VFS(M,R,V)-24,30)
NS 11788 DECORATIVE ROCK (2 REQ’D)
NS R-2809 DAMPER CLAMP (INCLUDED IN HARDWARE
PACKAGE)
MILLIVOLT SySTeM
6 R-3624 PILOT NAT
6 R-3623 PILOT LP
8 R-7063 PILOT REGULATOR (NAT ONLY)
10 11286 BURNER SUPPORT - RIGHT (16)
10 11375 BURNER SUPPORT - RIGHT (18,24,30)
11 R-4323 GAS VALVE NATURAL
11 R-4324 GAS VALVE LPG
NS 11292 TUBING - VALVE TO PILOT - LPG
NS 14039 TUBING - VALVE TO PILOT REGULATOR - NAT
NS 14041 TUBING - PILOT REGULATOR TO PILOT - NAT
NS 11291 TUBING - VALVE TO BURNER
NS R-5668 IGNITOR WIRE
NS R-5910 SWITCH LOG ASSEMBLY (INCLUDES SWITCH
AND WIRE)
NS R-5757 OFF/ON SWITCH
NS R-5699 WIRE HARNESS
VArIABLe SySTeM
6 R-5170 PILOT LP
6 R-5171 PILOT NAT
8 R-7063 PILOT REGULATOR (NAT ONLY)
10 11333 BURNER SUPPORT - RIGHT (16)
10 11308 BURNER SUPPORT - RIGHT (18,24,30)
12 R-5672 GAS VALVE NATURAL
12 R5673 GAS VALVE LPG
NS 11335 TUBING - VALVE TO PILOT-LPG
NS 14040 TUBING - VALVE TO PILOT REGULATOR - NAT
NS 14041 TUBING - PILOT REGULATOR TO PILOT - NAT
NS 11291 TUBING - VALVE TO BURNER
NS R-5797 REMOTE KIT
MANuAL SySTeM
6 R-5170 PILOT LP
6 R-5171 PILOT NAT
10 11481 BURNER SUPPORT - RIGHT
13 15414 REGULATOR MOUNTING BRACKET
14 R-2480 INLET REGULATOR - LP
14 R-2479 INLET REGULATOR - NAT
15 R-2313 PIEZO IGNITOR
16 R-2783 CONTROL KNOB
17 15416 VALVE BRACKET
18 R-4499 GAS VALVE - LP
18 R-4495 GAS VALVE - NAT
19 15494 COVER PLATE
NS R-5668 IGNITOR WIRE
NS 15528 TUBING ASSEMBLY - INLET REGULATOR TO
VALVE
NS 15529 TUBING - VALVE TO BURNER
NS 15530 TUBING - VALVE TO PILOT
PArTS LIST
Index
No.
Part
No.
Description
MILLIVOLT SySTeM (continued)
