10 GB
Mark the two fastening holes on the
desired installation location approx.
20 cm apart.
For furniture installation: Ensure
that the 12 mm screws are suitable
for installation on your furniture.
Drill two holes in the areas marked
with a 2 mm wood bit.
Secure the mounting brackets 5 , by
screwing the screws 2 in the holes.
For wall installation: Ensure that
the wall plugs
4 provided are suitable
for your chosen material. The wall
plugs are designed for masonry.
Drill a 6 mm hole in the marked area
with a masonry drill.
Put the wall plugs in the hole.
Secure the mounting bracket by screw-
ing the screws
3 into the wall plugs.
Attach the light to the secured mount-
ing bracket
5 .
Plug the lead 7 in the input socket
of your under cabinet light.
Then plug the European plug of the
lead in a socket.
Your under cabinet light is now ready for
operation.
