Introduction
Energy-saving spotlight
Introduction
We congratulate you on the purchase
of your new device. You have chosen a
high quality product. Familiarise yourself
with the product before using it for the first time. In
addition, please carefully refer to the operating
instructions and the safety advice below. Only use
the product as instructed and only for the indicated
field of application. Keep these instructions in a
safe place. If you pass the product on to anyone
else, please ensure that you also pass on all the
documentation with it.
Intended use
This spotlight is suitable for use indoors and in shel-
tered outdoor areas. The product has an infrared
sensor which detects heat movements and switches
the lamp on and off automatically. Any use other
than that described above or any modification of
the product is not permissible and will result in
damage. Moreover, there is the risk of injury or loss
of life or that the device may develop technical
faults (e.g. short circuit or fire or electric shock). The
manufacturer is not liable for damage caused by
improper use. The product is not intended for com-
mercial use.
Description of parts
1 Screw
2 Cable terminal box
3 Cable bushing IP44
4 Screw for IP 44
5 Nut
6 Wall bracket
7 Locking screw (motion detector)
8 Motion detector
9 Front panel
10 Bulb
11 Lead (electricity)
12 Screw terminal
13 Rotary control LUX (light sensitivity)
14 Rotary control TIME (switched on duration)
15 Rotary control SENS (sensitivity)
Technical Data
Spot:
Type designation:
ESS 23 PIR-A IP44
Nominal voltage: 220 – 240 V ~, 50 Hz
Light bulbs: energy saving bulb, E27,
23 W spiral shaped light
bulb
220 – 240 V ~, 50 Hz
(included in delivery)
Rated power: max. 25 W
Protection class: II /
System of protection: IP 44 (splash-proof)
Dimensions: 230 x 255 x 119 mm
(W x H x D)
Weight: 1050 g
Energy efficiency class: A
Motion detector:
Coverage angle:
max. 180°
Alignment: approx. 170° horizontally
approx. 180° vertically
(adjustable)
Width of coverage: 7 - max. 12 m
Duty cycle: 10 s - 11 min (adjustable)
Scope of delivery
Check that all the items and accessories are pre-
sent and that the device is in perfect condition
immediately after unpacking.
1 Energy-saving spotlight with motion detector
1 Light bulbs (energy saving bulb 23 W) spiral
shaped light bulb
2 Screws for wall mounting
2 Dowels (suited for concrete walls)
1 Operating
instructions
