background image

Electrolux Blast Freezers

Blast Chiller/ Freezers - 56 kg 20 GN1/1

Internet: http://www.electrolux.com/foodservice

HDBA030

2011-06-10

Subject to change without notice

TROLLEY FOR 20X1/1 ROLL-IN RACK

922132

922132

RILSAN COATED GRID

881061

881061

REMOVABLE TRAY SUPPORT RACK FOR 20 GN1/1

881010

881010

RACK RAILS FOR VERTICAL BLAST CHILLER

881182

881182

PRINTER HACCP BASIC VERS-REF.ELECR.CONTR

881532

881532

PLASTIC COATED GRID-600X400 MM

880864

880864

PAIR OF 1/1 GN AISI 304 S/S GRIDS

921101

921101

KIT HACCP ADVANCED CONNECT. BC/BCF LW+CW

880183

880183

80MM PITCH ROLL-IN RACK 14X1/1GN

922205

922205

60-MM PITCH ROLL-IN RACK FOR 20X1/1

922203

922203

3-POINT-SENSOR PROBE-BL.C/FREEZERS LW

880212

880212

3 SINGLE-SENSOR PROBES-BL.C/FREEZERS LW

880215

1 SINGLE-SENSOR PROBE-BL.C/FREEZERS LW

880213

880213

ACCESSORIES

REMOVABLE TRAY SUPPORT RACK FOR 20 GN1/1

4

4

1 SINGLE-SENSOR PROBE-BL.C/FREEZERS LW

1

1

INCLUDED ACCESSORIES

Power supply - V, phases, Hz

400 V, 3N, 50

220 V, 3N, 60

Net weight - kg.

235

235

installed-electric

3.93

4.216

Power - kW

at evaporation temperature - °C

-5

-5

Refrigerant power

Refrigeration power - W

9054

4520

Refrigerant quantity - g.

3600

3600

Refrigerant type

R404a

R404a

N° defrost in 24 hrs.

3

Compressor power - HP

3

2.8

Max load capacity - trays h 65 mm - n°

12

Trays type

GN 1/1; 600x400

GN 1/1; 600x400

Door hinges

Right Side

Right Side

height

2230

2230

depth/with open doors

835, 1570

835, 1570

width

800

800

External dimensions - mm

Cooling unit

Built-In

Built-In

Gross capacity (D.I.N. 8952) - l.

560

560

UK Guide lines - chilling / freezing

64, 56

NF Regulations - chilling / freezing

43.2

Productivity per cycle - kg.

Power supply

Electric

Electric

TECHNICAL DATA

RBF201

726630

RBF2016

727133

CONSTRUCTION

Internal and external finishing in 304

AISI stainless steel and backpanel in
galvanized steel.

High density polyurethane

insulation, 60 mm tickness, HCFC
free.

Environmentally friendly: R404a as

refrigerant fluid.

Developed and produced in ISO

9001 and ISO 14001 certified factory.

Inner cell with fully rounded corners.

Door equipped with removable

magnetic gasket with hygienic design.

Motors and fan waterproof

protected IP21.

Evaporator with antirust protection.

Ventilator (fan) swinging hinged

panel for access to the evaporator for
cleaning.

Automatic heated door frame.

Thermostatic expansion valve to

optimize the cooling unit efficiency.

Adjustable feet 150 mm high.

Stand alone printer as accessory.

PC connection on request, gate RS

485.

INSTALLATION

No water connections required.

Waste water can be plumbed into

drain, but can also be collected in an
optional waste container.
