DO NOT leave machine running unattended. Turn power supply OFF and DO NOT leave the vicinity until motor has come to a
complete stop.
DO NOT operate the cleaner while under the influence of drugs, alcohol or impairing medication, or if you are tired.
DO NOT use the cleaner in the rain or in very damp conditions.
DO NOT use the cleaner in the rain or in very damp conditions.
R WARNING! The warnings, cautions and instructions in this manual cannot cover all possible conditions and situations that may
occur. It must be understood by the operator that common sense and caution are factors which cannot be built into this product,
but must be applied by the operator.
R NOTE: This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of
the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
2. INTRODUCTION
Cleans carpets, car interiors, fabrics and upholstery. Constructed from high impact plastic which is dent resistant and rust proof. Supplied
complete with carpet lance, hand-held lance, full wet and dry vacuum accessory kit, including stainless steel telescopic rigid extension
tube, cartridge filter and foam filter. Powerful pump forces cleaning fluid into fabric/carpet and 1250Watt suction power leaves surface
virtually dry after one pass. Features safety shut-off for wet operation. Large capacity drum with external detergent tank for easy filling.
Fitted with two fixed wheels and two castors. Cable storage hook, accessories and extension tube holders on head plus additional
accessory stowage slots on base.
3. SPECIFICATION
4. CONTENTS
4.1. Undo tank clasps and lift off the top section assembly.
4.2. Remove contents from inside the tank. Check and identify each component as listed in fig.1.
ITEM DESCRIPTION
1. Handle.
2. Exhaust outlet cover for HEPA
filter
3. HEPA filter
4. Shut-off valve basket.
5. Floating cup valve.
6. Cable storage hook
7. Accessory storage position
8. Extension tube holder
9. Main switch
10. Shampoo pump outlet nozzle
11. Vacuum hose inlet.
12. Castor in castor mounting with
accessory storage.
13. Rear wheels.
14. Rear storage container
15. Clasp. (x2)
16. Rear shampoo tank connecting
tube
17. Shampoo tank.
18. Cartridge filter.
19. Shampoo pipe for large wash
head
20. Large shampoo head
21. Shampoo spraying nozzle
22. Small shampoo head
23. Air flow regulator
24. Extension tube
25. Foam filter
26. Combo floor brush
27. Crevice tool
28. Small utility nozzle
29. Suction hose, and shampoo
delivery tube assembly
30. Tube clip
31. Sprayer trigger
32. Seal ring (for replacement)
33. Hose connector
fig1
Model No: .................................................................... PC310
Motor: ..........................................................................1250W
Supply: .................................................................230V, 50Hz
Drum Size: ......................................................................20ltr
Weight ............................................................................ 10kg
Filter - Dry: .............................................................. Cartridge
Filter - Wet ..................................................................Foam
Replacement Cartridge Filter: ................................ PC310CF
