S100 Active Low Frequency Monitor Specifications
Low Frequency Driver
8” polypropylene cone with damped rubber surround and high-temperature voice
coil.
Frequency Response
35Hz – 120Hz, -3dB
Amplifier Power
100W, Linear
LFE Crossover
120Hz, 2nd-order
Noise
>70dB below full output
Inputs
Mono line input with 1/4” connector; Left and Right line inputs with RCA connectors;
All unbalanced.
Pass-Through Outputs
Two RCA mains monitor channel pass-throughs
Controls
Input Sensitivity; mains power; operating voltage selection; on/off mute (footswitch-
controlled)
Power Requirements
200VA, User selectable 110V~ 60Hz or 220/240V~ 50-60Hz mains
Polarity
Positive signal at input produces outward cone displacement
Cabinet
5/8” vinyl-laminated MDF, internally insulated
Dimensions
12” W x 16-5/8” H x 10-3/4” D
Weight
32lbs
Specifications subject to change without notice.
