Eureka 2900 Series - Manual (Page 3)

3 www.eureka.com
Assembly Parts
1 Wand and Crevice Wand. (Pull apart.)
2 Dusting Brush.
3 Hose.
4 Vacuum Cleaner Body.
5 Electrical Cord.
6 Handle.
7 Screws located in the accessory package.
1
2
3
4
5
6
How To Assemble
CAUTION: Assemble the cleaner before using.
CAUTION: Moving parts, make sure ON/OFF switch is in
the OFF position before plugging in.
1 Grasp dust bag cover
handle and pull away
from vacuum body to
remove door.
2 Slide the handle into
the grooves at the
top of the vacuum
body as shown.
3 Place the two screws
(supplied)into the
holes at the top of
the bag compartment
and tighten with a
screwdriver.
4 Place the tabs on the
bottom of the dust
bag cover into slots
at the bottom of the
bag
compartment
and rotate door up
and push against the
vacuum body until it
snaps shut.
5 Place the hose
on the back of the
vacuum, wrapping it
up and over the hose
hook as shown.
6 Firmly push the end
of the hose into the
hose retainer in the
hood of the vacuum.
