OPERATING INSTRUCTIONS

2. Remove the filter assembly from the

dust cup container.

3. To separate the filter assembly, hold

the bottom of the filter frame and

pull the HEPA-Type filter out.

(Fig. 9)

How to Start

The vacuum can be used on multiple

types of carpeting or bare floors. When

using the crevice tool or dusting brush,

place the handle of the vacuum in the

upright position.

1. Plug the power cord into the electrical

outlet.

2. Push the On/Off

button to the "On"

position to turn

the vacuum on.

3. To release the

handle, step

on the handle

release pedal

and pull back handle.

4. When using the crevice tool or dusting

brush, the vacuum must be in the

upright position. (Fig. 4)

Store or use

attachments

Use

Clean under

furniture

Handle release

Warning:

To reduce the risk of electric

shock, the power cord must be

disconnected before removing the dust

cup (container), dust cup HEPA-Type

filter, changing the pre-motor filter or

performing maintenance/trouble shooting

checks.

Important:

Do NOT use the vacuum

without ALL the filters in place.

The “Dust Cup (Container)” must always

be emptied when the dirt level reaches

the “FULL" line on the dust cup

(container). To remove the dust cup

(container) from the vacuum:

1. Press down on the dust cup

release button that is located on the

dust cup cover handle of the dust

cup. (Fig. 6)

Removing & Emptying Dust Cup
(Container)

Place unit in “UPRIGHT" position when

using attachment or hose to prevent

possible floor damage. Always set the

carpet height selector to “highest”

setting when using the accessories and

hose.

Attention

: Special care is required

when vacuuming certain types of carpet

or floor covering. Always check the

carpet or floor covering manufacturer's

recommended cleaning instructions

before vacuuming.

Carpet Height Selector

This upright vacuum can be used on

multiple types of carpeting and bare

floors. To select a pile height setting:

1. Turn vacuum cleaner "Off".

2. Select a pile height setting by

rotating the carpet height selector

to the desired setting. (Fig. 5)

Carpet height
selector

HIGH:

shag carpet, long pile, plush

scatter rugs, tools

MED:

medium to long pile

LOW:

very low pile, bare floors

Suggested Pile Height Setting:

You may need to raise the height of the

vacuum to make some jobs easier,

such as scatter rugs and longer pile

carpets. Suggested settings are:

Fig. 4

Fig. 5

Dust Cup

Release Button

Fig. 6

2. To empty the dust cup container,

hold the dust cup from the handle

over a garbage container and press

on the trap door release button that is

on the back side of the dust cup

container to release the dust cup

bottom. (Fig. 7)

Fig. 8

Open

Mark

Arrow

for

alignment

•

The dust cup container can be

washed in lukewarm water.

•

Do not use strong detergents.

•

Ensure that the dust cup container

is fully dry before putting back on

the vacuum cleaner.

•

Do not wash in dishwasher.

IMPORTANT

, Please Note: The

Rinseable “TapClean” HEPA-Type Dust

Cup Filter will quickly accumulate many

fine dust particles inside the white filter

folds that are difficult to see but which will

eventually block or reduce your suction

power - if not cleaned properly. Clean the

HEPA-Type Filter after each use as

described in this section.

Warning

After each Use - Always

remove the Filter Assembly, then

vigorously tap clean the HEPA-Type

Filter until no more dust can be

removed.

Fig. 7

Trap Door

Release Button

Cleaning the HEPA Filter and the
Filter Frame

1. To remove the filter assembly from

the dust cup, hold the dust cup

cover from the handle in one hand

and with the other hand, turn the

dust cup container counter

clockwise. (Fig. 8)

4. Remove the filter ring that is

around the

HEPA-Type

filter. Then

vigorously

“TapClean” the

HEPA-Type Filter on a hard

surface until no more dust is

observed falling out.

5. To clean the filter

frame, we

recommend that

you rinse it under

lukewarm running

water to remove

the dirt that

accumulates

on it, but always

allow 24 hours to air dry before

inserting back into the vacuum.

6. To re-assemble the filter

assembly, insert the filter ring over

the HEPA-Type filter and then

insert the HEPA-Type filter

assembly into the filter frame.

Replace the filter assembly into

the dust cup container. Replace

the dust cup container cover.

HEPA-Type

Filter

Frame

Filter
Ring

Filter Assembly

Fig. 9
