Page 10

Figure 6: Handles for Removing Door.
Figure 7: Removing of Door.
Maintenance And Service
R
ePLacing
the
g
Lass
:
The glass in the fireplace is a high temperature ceramic. If the glass is damaged in any way, a factory
replacement is required (see P
artS
l
iSt
- c
oMPonentS
). Wear gloves when handling damaged glass door
assembly to prevent personal injury. When the glass door assembly is being transported, it must be
wrapped in newsprint and tape and/or a strong plastic bag. Do not operate with the glass front removed,
cracked or broken. Removal and replacement of the glass from the door must be done by a licensed or
qualified service person. The glass must be purchased from an ENVIRO dealer. No substitute
materials are allowed.
To Replace:
• Open door, and remove the glass carefully.
• Install the new piece of glass with the large bulb in the gasket tape against the unit. Place the joint
in the tape in a bottom corner. Close door.
g
Lass
D
ooR
R
emovaL
:
Turn unit off and wait until the appliance has cooled down. Remove the cast iron top from the unit by
lifting straight up. Lift the two door handles located on either side of the door and lift the glass door
b
uRneR
R
emovaL
:
1. Remove the glass as shown in the M
aintenance
and
S
ervice
- G
laSS
d
oor
r
eMoval
.
2. Carefully remove the log set and ember material.
3. Remove the two (2) screws (located on the outside edges of the burner) that hold the burner to the
chassis inside the fire box, see Figure 8. Remove the burner tray from the firebox.
10
assembly straight up and out (see Figure 6 and 7).
Carefully open the two doors and remove if necessary.
Ensure the door is properly fastened after cleaning before
attempting to re-light the appliance.
