PE-225 SPECIFICATIONS
X7722272307 29
© 3/2013 ECHO Inc.
SPECIFICATIONS
MODEL PE-225
Length 1772 mm (68.6 in.)
Width 305 mm (12.0 in.)
Height 370 mm (14.6 in.)
Weight (dry) w/Cutter Head 6.0 kg (13.2 lb.)
Engine Type Air cooled, two-stroke, single cylinder gasoline engine
Bore 32.2 mm (1.27 in.)
Stroke 26.0 mm (1.02 in.)
Displacement 21.2 cc (1.29 cu. in.)
Exhaust Spark arrestor muffler or spark arrestor muffler with catalyst
Carburetor Diaphragm w/purge pump
Ignition System Flywheel magneto, capacitor discharge ignition type
Spark Plug NGK BPM-8Y (Gap 0.65 mm (0.026 in.)
Fuel Mixed (Gasoline and Two-stroke Oil)
Fuel/Oil Ratio
50 : 1 Power Blend X TM ISO-L-EGD (ISO/CD 13738) and J.A.S.O. M345- FD, two-stroke,
air-cooled engine oil.
Gasoline
Use 89 Octane unleaded. Do not use fuel containing methyl alcohol, more than 10% ethyl
alcohol or 15% MTBE. Do not use alternative fuels such as E-15 or E-85.
Oil Power Blend X TM Premium Universal 2-Stroke Oil
Fuel Tank Capacity 0.44 lit. (14.9 US fl. oz.)
Starter System Automatic Rewind Starter
Clutch Centrifugal Type
Drive Shaft 6.15 mm (1/4 in.) flexible shaft
Gear Case Ratio 1.57:1 Reduction
Rotating Direction Clockwise; viewed from right side
Standard Cutter Head Metal blade
Blade Length 203.2 mm (8.0 in.)
Blade Width 50.8 mm (2 in.)
Blade Thickness Standard 2.3 mm (0.090 in.), Premium 4.6 mm (0.181 in.)
Handle Front D-loop, Rear - Grip
Idle Speed 2,750 RPM
Clutch Engagement Speed 3,800 RPM
Wide Open Throttle Speed (W.O.T.) 10,500 RPM
