Edimax Technology EU-4230 - Manual (Page 15)

12
3. Specifications
USB
Upstream port x 1 (USB Type A plug)
Downstream port x 3 (USB Type A receptacles)
Compliance : USB1.1 & USB 2.0
LAN
RJ-45 x 1 (Ethernet 10BASE-T/Fast Ethernet 100Base-TX port)
Complies with the Full-duplex with flow control and Half-duplex
with backpressure operation
Power Supply Input : 100~240v 50Hz-60Hz Output: 5V 2.5A
LED
Blue LED for Power-on indication
Green LED for Ethernet Connection indication
Housing
Size (Lx W x H) : 98 x 36 x 20 mm
Material : plastic (ABS)
Weight : 46G
Power Mode
Bus-powered : 5V 500mA
Self-powered : 5V 2.5A
Adapter：
Input : 100~240V 50Hz ~60Hz
Output : 5V/2.5A
Working
Environment
Operation temperature : 0 ~ 70 degree
Storage temperature : -10 ~ 80 degree
Certification : FCC, CE
