2.REPLACING SPOOL
NOTE
Keep line tight on spool.
A. Snap spool into housing while pulling line through eyelets with
about 15 cm (6 in) extending out.
CAUTION
Knob tightens counterclockwise, “left”.
B. Fasten spool to housing with shaft bolt, spring, and knob.
12
CUTTING PROCEDURES
Locking tool
Upper fixing plate
TIGHTEN
Cutting head
operatIng InstructIons nylon lIne
1. Always use the end of the line for cutting. Forcing the cutter head
too close to the work will result in reduced efficiency and broken
line.
2. Maintain the line at the recommended length of 12.5 to 15 cm (5
to 6 in). A longer line will reduce engine speed, a shorter line may
result in engine damage.
3. The trimmer head rotates counterclockwise. Always cut with the
head tilted to the right to deflect debris away from the operator.
4. Always observe the SAFETY RULES on Page 5 when using the
unit.
