7. ELECTRICAL CONNECTIONS
6. INSTALLATION OF SAFETY SUPPORT
(for Canadian Installation ONLY)
A safety support cable is provided to help
prevent the ceiling fan from falling, please install
it as follows.
Step 1. Attach the provided wood screw and
washers to the ceiling joist next to the mounting
bracket but do not tighten. (Fig. 11)
Step 2. Adjust the length of the safety cable to
reach the screw and washers by pulling the
extra cable through the cable clamp until the
overall length is correct, put the end of the cable
back through the cable clamp, forming a loop at
the end of the cable. Tighten the cable clamp
securely. Now, put the loop in the end of
the safety cable over the wood screw and under
the washer. Tighten the wood screw securely.
Ceiling mounting
bracket
Attach
safety cable
to ceiling joist
with screw and
washer
Fig. 12
WARNING: To avoid possible electrical shock,
be sure you have turned off the power at the
main circuit panel.
Follow the steps below to connect the fan to
your household wiring. Use the wire connecting
nuts suppled with your fan. Secure the
connectors with electrical tape. Make sure there
are no loose wire strands or connections.
Step 1. Connect the fan supply (black) wire and
light supply (blue) wire to the black household
supply wire as shown in Figure 12.
Step 2. Connect the neutral fan (white) wire to
the neutral household (white) wire.
Step 3. Connect the fan ground wire (green) to
the household ground wire.
Step 4. After connecting the wires, spread them
apart so that the green and white wires are on
one side of the outlet box and the black and the
blue wires are on the other side.
Step 5. Turn the connecting nuts upward and
push the wiring into the outlet box.
WARNING: TO REDUCE THE RISK OF FIRE,
ELECTRIC SHOCK OR OTHER PERSONAL
INJURY, MOUNT YOUR CEILING FAN ON A
OUTLET BOX OR SUPPORTING SYSTEM
MARKED "ACCEPTABLE FOR FAN
SUPPORT".
BLUE
BLK
BLK
GRN
Wiring
box
Ground to
mounting
bracket
or downrod
BLUE
BLUE
FAN
LIGHT
Power lines 220~240V
Green ground
RED
RED
BLK
BLK
