REMARKS

DESCRIPTION

QTY

PART NUMBER

ITEM

CIRCLIP 42

1

90070200042

1

FIXTURE, MAIN PIPE

1

61092255931

2

SCREW 5X28

1

90016205028

3

SCREW 5X18

2

90016205018

4

CLIP

1

17811106230

5

INCLUDES ITEMS 7-12

FAN COVER ASY

1

P021001410

6

CIRCLIP 12

1

90070100012

7

CASE, FAN

1

A172000030

8

DOWEL PIN

2

V622000020

9

BEARING, BALL - 6001

2

90080796001

10

CIRCLIP 28

1

90070200028

11

DRUM, CLUTCH

1

A556000030

12

SHOE, CLUTCH

2

A553000010

13

SHAFT, CLUTCH

2

17504656030

14

WASHER

2

17504956030

15

SPRING, CLUTCH

1

V451000090

16

WASHER

2

17504805530

17

99922204021

- 9 -

REVISED 10/11/07
