REMARKS

DESCRIPTION

QTY

PART NUMBER

ITEM

WING BOLT

1

21041752730

1

LID, AIR CLEANER - GRAY

1

13031306563

2

LID, AIR CLEANER - BLACK

1

13031305863

3

FILTER, AIR

1

1

13031054130

4

PLATE, PREVENT

1

12901152730

5

SCREW 5X60

2

90024205060

6

CASE, AIR CLEANER - GRAY

1

P021000991

7

CASE, AIR CLEANER - BLACK

1

P021004480

8

See Carburetor Diagrams For Additional Information

CARBURETOR

1

------------------

9

GASKET, INTAKE

2

1

13001013410

10

INSULATOR

1

13001756431

11

SCREW 5X25

2

90016205025

12

GASKET, INTAKE

2

1

13001055930

13

Footnotes

1: Also Included In REPOWER TUNE-UP KIT
2: Also Included In GASKET KIT

99922204021

- 13 -

REVISED 10/11/07

Table of Contents

Part Number Index

SRM-230 Trimmer

Intake
