EVO 3i MOTORIZED TREADMILL

Visit us at: www.evofitness.com

15

ASSEMBLY

STEP 6:

Attach the Handlebar Rear End Cap – Left #1 (6) to the Handlebar Rear End Cap – Left #2 (7) over the Left Upright (17) and
secure in place using two #8 x 19mm Screws (10) and two #8 x 25mm Screws (11). Attach the Handlebar Rear End Cap –
Right #2 (9) to the Handlebar Rear End Cap – Right #1 (8) over the Right Upright (18) and secure in place using two #8 x
19mm Screws (10) and two #8 x 25mm Screws (11).
