Part names, Accessories – Electrolux TINSEB493MRR1 User Manual
Page 10

E
10
Part names
Control panel
1
Ventilation openings
2
model / Serial label
3
Door seals and sealing surfaces
4
Safety door latches — The oven will not
5
operate unless the door is securely closed.
Oven door with see-through window
6
Door handle
7
Door hinges
8
Turntable motor shaft
9
menu label
10
Oven light — It will light when oven is operating
11
or door is open.
Waveguide cover: DO nOT REmOVE.
12
Time display: 99 minutes, 99 seconds
13
Popcorn/Bacon Tray
14
Removable turntable — Place the turntable on
15
the turntable support securely. The turntable
will rotate clockwise or counterclockwise. Only
remove for cleaning.
Removable turntable support — Carefully place
16
the turntable support in the center of the oven
floor.
High Rack
17
Low Rack
18
Convection Fan
19
11
2
12
1
9
10
3
4
8
5
7
6
13
19
16
15
14
18
17
Accessories
The following accessories are designed especially
for use in this oven only for convection, mix or broil
cooking. DO nOT USE FOR mICROWAVE OnLY
COOKInG. Do not substitute similar types of racks
for these specially designed ones.
High rack (Baking rack)–for
convection and low mix.
This rack is placed
•
on the turntable for
two-level cooking,
such as layer cakes,
muffins, etc.
Low rack (Broiling rack)–
for convection, broiling or
high mix.
Place on the turntable
•
and use for roasting or
broiling to allow juices
to drain away from food.
