Page 7

17375-10-0706

Figure 1

DVP42

DVP48

A

43"
1092mm

49"
1245mm

B

40"
1016mm

46"
1168mm

C

25 1/16"
636 mm

25 1/16"
636 mm

D

37 5/8"
956 mm

37 5/8"
956 mm

E

34 3/4"
883 mm

34 3/4"
883 mm

F

19 7/8"
505 mm

19 7/8"
505 mm

G

26"
660 mm

26"
660 mm

H

7 1/8"
181 mm

7 1/8"
181 mm

I

26 1/2"
826 mm

32 1/2"
826 mm

J

13 1/4"
337 mm

16 1/4"
413 mm

K

12 3/4"
324 mm

12 3/4"
324 mm

RIGHT SIDE VIEW

J

H

K

Remote Control Options &

Accessories

Description

FRBC

Millivolt Batt. Remote ON/OFF

FRBTC

Millivolt Batt. Remote T-Stat

TMW

Millivolt WIRELESS Wall Thermostat

TRW

Millivolt REED SWITCH Wall Thermostat

FWS-1

Direct Ignition/Millivolt Wall Switch

Venting Options

Description

DVVK-5TS

TOP VENT KIT (HORZ.) - 4½" to 6" wall

thickness (114.3mm to 152mm)

DVVK-5T

top vent kit (horz.) - 8" to 12" wall thickness

(203mm to 305mm)

DVVK-5R

rear vent kit (horz.) - 5" to 7" wall thickness

(203mm to 305mm)

DVVK-5V

VERTICAL vent kit

DVVK-5F

HORIZONTAL FLEX VENT KIT (4' FLEX)

(1.22M)

DVP42

DVP48

Input Btu/hr Maximum

28,000

30,000

Btu/hr Minimum (millivolt only)

19,000

20,500

KWH (Maximum)

8.2

8.8

(Minimum)

5.5

6.0

NAT.

Orifice

#38 (.1015)

P-203

#37 (.1040) P-213

Air Shutter Opening

1/8"(3.2mm)

1/8"(3.2mm)

LP

Orifice

#52 (.0635")

P-213

1.65MM

P-250

Air Shutter Opening

FULL OPEN

FULL OPEN

Height without standoff

34 3/4"(3.2mm) 34 3/4"(3.2mm)

Width

43"(1092mm)

49"(1245mm)

Depth

19 7/8"(505mm) 19 7/8"(505mm)

Gas Inlet Shutoff Valve (Pipe)

1/2 NPT

1/2 NPT

NOTE: Air shutter settings

are factory minimum settings.

Some venting configurations

may require minor air shutter

adjustments for optimum

performance.

SPECIFICATIONS

FIREPLACE DIMENSIONS
