17375-10-0706
INDEX
NO.
PART NUMBER
DESCRIPTION
DVP42
DVP48
26
P200
P200
ORIFICE FITTING
27
P203
P213
ORIFICE (NAT)
27
P185+
P250
ORIFICE (LP)
28
R-5676
R-5676
AIR SHUTTER
29
11499
11499
BURNER BRACKET LEFT
30
11377
11377
BURNER BRACKET RIGHT
31
17370
17386
SLOPE BURNER
32
17368
17385
BURNER BASE PLATE ASSEMBLY
33
17369
17369
TUBING ASSEMBLY
34
R-2423+
R-2423+
MALE CONNECTOR
35
R-1109+
R-1109+
BUSHING, FLUSH TYPE (IP ONLY)
36a
R-7577
R-7577
VALVE, SIT GAS (NAT)
36a
R-7578
R-7578
VALVE, SIT GAS (LP)
36b
R-5745
R-5745
VALVE, INTERMITTENT PILOT GAS (NAT)
36b
R-5746
R-5746
VALVE, INTERMITTENT PILOT GAS (LP)
36c
R-6114
R-6114
VALVE, RF GAS (NAT)
36c
R-6115
R-6115
VALVE, RF GAS (LP)
37a
17161
17161
VALVE BRACKET (SIT)
37b
17795
17795
VALVE BRACKET (IP)
37c
17796
17796
VALVE BRACKET (RF)
38
16223
16223
SPRING LATCH ASSEMBLY
39a
R-3435
R-3435
WIRING HARNESS (SIT)
39b
R-5751
R-5751
WIRING HARNESS (IP)
40
R-2708+
R-2708+
PIEZO IGNITOR
41
R-3436+
R-3436+
REMOTE OFF/ON SWITCH
42
R-1995+
R-1995+
TRANSFORMER (IP)
43
R-5160
R-5160
TRANSFORMER CORD SET (IP)
44
R-1616+
R-1616+
CONTROL MODULE (IP)
45
R-721+
R-721+
WIRING ASSEMBLY (IP)
46
-
-
AIR DEFLECTOR (RF)
47
18858
18858
BLOWER BASE (RF)
48
R-7731
R-7731
BLOWER MOTOR ASSEMBLY (RF)
49
R-7831
R-7831
BLOWER CORD SET (RF)
50
R-7643
R-7643
TOP LOG - TWIG
51
R-7642
R-7642
REAR LOG
52
R-7641
R-7641
MAIN LOG
PARTS LIST (continued)
Use Only Manufacturer’s Replacement Parts. Use of Any Other Parts Could Cause Injury Or Death.
