This portable air conditioner is designed to exhaust most or
all water condensed from the air (in cooling mode). In high
humidity situations, the internal water reservoir may fill. The
unit will automatically shut off and the water light will turn on.
Once the water is manually drained, the unit will operate as
normal.
Water Light
Speed Mode POWER Timer
WATER
Operation
Mode
This unit has 4 settings:
• Cooling • Dehumidifying • Fan • Heating
The settings are adjusted by pressing the mode button. Icons
on the LCD display will indicate which setting is currently being
used.
• Cooling Mode
When the cooling mode is selected, “ ” will show in
the LCD display. In cooling mode, room air is
cooled and hot air is exhausted to the outside
through the exhaust hose. Adjust the fan speed and
air temperature to suit your desired comfort level.
Note: The exhaust hose must vent outside the
room when using the cooling mode.
• Dehumidifying Mode
When dehumidifying mode is selected, “ ” will show
in the LCD displa y. The dehumidifying mode removes
• Fan Mode
When the fan mode is selected, “ ,” “ ,” or “ ” will
be shown in the LCD displa y, and air is circulated
throughout the room with no cooling.
Note: unit does not need to be vented in Fan mode
• Heating Mode
When the heating mode is selected, “
LCD Display
Timer Button
Fan Speed Button
Mode Button
Power Button
Timer/Temp
Set Button
After turning the air conditioner off, wait 3 minutes before turning it back on again.
water from the air without cooling the room. If the
room temperature is below 77ºF, the fan speed will
be locked on “low;” above 77ºF, the fan speed is
adjustable.
Note: The exhaust hose is not required in
dehumidifying mode. Note that the internal
water tray will fill with water in this mode.
Power
To set the temperature in cooling or heating mode use the
“ ” and down “ ” buttons. The temperature setting
range is from 61 ° F- 89 ° F.
Note: When in dehumidifying or fan mode,
temperature setting is not required or allowed.
Note: Inital setting is in ºF.
Temperature
Pressing both the timer/temp set buttons (“ ” and “ ”)
will switch the temperature read-out between ºC and ºF.
Cancelling the Timer
You may cancel the timer setting at any time by
pressing the timer button once you have set the timer or
by pressing the power button.
Fahrenheit/Celsius
• Used for adjusting the timer and thermostat.
• The default display is room temperature.
• In cooling and heating modes, you can set the
temperature by pressing the “ ” and “ ” buttons.The set
temperature will be displayed for 10 seconds, then revert
back to room temperature.
• The timer can be set by pressing the “
• The timer is adjustable between 1-24 hours.
• Once the timer has been set, the adjusted time will be
displayed for 5 seconds, then the display willrevert back
to the displaying the room temperature.
Water Light
• The power button turns the unit on and off.
• When you first press the power button, the unit will begin to
operate in cooling mode. After you have used the unit, and
turned it off, it will default to the last used mode/settings
upon turning the unit on again. If power to the unit is
interrupted while the unit is running, the air conditioner
will restart itself in its last used mode/settings once power
is restored.
Note: This "auto restart" function will restart the unit after
power is restored. The compressor will resume after 3
minutes, if in use.
Timer/Temp Set Buttons
Temperature Display
Water Warning
-the machine will
stop running
Dehumidifying Mode
Cooling Mode
Fan Mode
High Fan Speed
Medium Fan Speed
Low Fan Speed
Timer Setting Display
ON OFF
Heating Mode
Transmitting
” will be
shown in the LCD display. In heating mode, room air
is heated and cool air is exhausted to the outside
through the exhaust hose. Adjust the fan speed and air
temperature to suit your desired comfort level.
Note: The exhaust hose must vent outside the room
when using the heating mode.
up
” and adjusting
the “ ” and “ ” buttons.
Fan Speed
The unit has 3 speeds: Low, Medium and High. Press the
speed button to toggle the speeds.
