SHOULDER ROTARY MOWERS CONVERTIBLE FOR METAL BLADE USE
COUNTER-
CLOCKWISE
HEAD ROTATION
STRAIGHT SHAFT
MODELS
SRM SERIES
GRASS/WEED/BRUSH CUTTERS
STOP SWITCH
THROTTLE
LEVER
D-HANDLE ON SOME MODELS IS SUITABLE
FOR NYLON LINE TRIMMING, BUT MUST BE
REPLACED WITH A U-HANDLE IF METAL
BLADES ARE TO BE USED
DEBRIS SHIELD
U-HANDLE REQUIRED
FOR USE WITH METAL BLADES
IS STANDARD ON THE LARGER
SRM MODELS
THROTTLE
LEVER
STOP SWITCH
SHOULDER/WAIST
HARNESS
NUT
ASSEMBLY TOOLS
METAL DEBRIS SHIELD
FOR USE WITH METAL
BLADES
DEBRIS SHIELD
OPTIONAL
BLADE
BLADE ADAPTER
PACKAGE OF COTTER
PINS
