Emotiva BPA-1 Power Amplifie
Professional Power Amplifier Features
• Audiophile quality power amplif er
• Full Range or Subwoofer Only Capabilities
• Adjustable Active Subwoofer Crossover, variable from 50-150Hz, 18dB/oct.
• Bridgeable in Full Range and Low Pass Mode
• 75 Watts x 2 into 4 Ohms
• 150 Watts x 1 into 8 Ohms (Bridged Configuration
• Gold Plated RCA inputs and “Pass Thru” outputs
• “Daisy Chain” capability with a single 2 channel input
• Thermal, Short Circuit, and Overload Protection Circuits
• Signal sensing auto turn-on and soft touch front panel power switch
• Silent turn on/off - No audible transients
• THD less than .01%, 20Hz-20kHz with 80kHz measurement bandwidth
• Signal to Noise Ratio >100dB
• IEC power inlet, 120 VAC (configurable to 230 AC)
Front Panel Layout
Power Switch
This manually turns on the
BPA-1. In the “Auto” mode,
this remains on by the amp
will be in standby mode until
an audio signal is sensed.
Level Control
This adjusts the output on
the BPA-1 to match the
speakers connected with
other speakers in the sys-
tem.
POWER
LEVEL
