Multi-Gas
Monitor
AT
X
612
1.
W
ARNINGS AND
C
AUTIONARY
S
TATEMENTS
3
2.
U
NPACKING
T
HE
I
NSTRUMENT
4
3.
ATX612 F
EATURES
4
4.
I
NSTRUMENT
O
PERATION
5
4.1 Charging the Battery
5
4.1.1
Alkaline Battery Option
8
4.2 Turning the ATX612 On and Off
8
4.3 Display Backlight
8
4.4 Internal Sampling Pump
8
4.5 Operating Modes
9
4.5.1 Reading
9
4.5.2
Sensor Configuration
9
4.5.3
PPM Hydrocarbon
9
4.5.4
Zero
9
4.5.5
Peak
9
4.5.6
Peak Clear
10
4.5.7
Date
10
4.5.8
Cal Date
10
4.5.9
Log Time
10
4.5.10 TWA
10
4.5.11 STEL
10
4.5.12 Hygiene Reset
10
4.6 Alarm Indicators
10
4.6.1
Low Alarm
10
4.6.2
High Alarm
11
4.6.3
Over-Range Indication
11
4.6.4
Combustible Gas Over-Range
11
4.6.5
Low Battery Warning
11
4.6.6
Battery Failure
12
4.6.7
Fault Indication
12
5.
C
ALIBRATING THE
ATX612
12
6.
C
HANGING
I
NSTRUMENT
S
ETTINGS
15
6.1 Setspan
15
6.2 Alarms
16
6.3 Code
17
7.
H
YGIENE
/D
ATALOGGING
F
UNCTIONS
17
7.1 Definition of Terms
17
7.1.1 Data Log
17
7.1.2 Period
18
7.1.3 Logging Session
18
7.1.4 Real Time Clock
18
7.1.5 Log Time Clock
18
7.1.6 Calendar
18
7.1.7 TWA
18
7.1.8 STEL
18
7.2 Principles of Operation
18
7.3 Resetting the Hygiene Functions
19
7.4 Downloading the ATX612
19
8.
M
AINTENANCE
20
8.1 Cleaning
20
8.2 Changing the Battery
20
8.2.1
Replacing the Nicad Battery Module
20
8.2.2
Replacing Alkaline Battery Cells
21
8.3 Opening the Instrument for Service
21
8.4 Installing or Changing Sensors
21
8.4.1
Toxic/Oxygen Sensor Removal/Replacement
22
8.4.2
Combustible Sensor Removal/Replacement
22
8.5 Changing the Internal Filter
22
9.
R
EPLACEMENT
P
ARTS
23
10.
S
PECIFICATIONS
26
11.
D
EFAULT
A
LARM
S
ETTINGS
27
12.
ATX612 O
PTIONS
& O
RDERING
I
NFORMATION
27
13.
W
ARRANTY
28
T
ABLE OF
C
ONTENTS
2
3
1.
W
ARNINGS AND
C
AUTIONARY
S
TATEMENTS
Failure to perform certain procedures or note certain
conditions may impair the performance of the
instrument. For maximum safety and performance,
please read and follow the procedures and conditions
outlined below.
Oxygen deficient atmospheres may cause combustible
gas readings to be lower than actual concentrations.
Oxygen enriched atmospheres may cause combustible
gas readings to be higher than actual concentrations.
Calibrate the combustible gas sensor after each
incident where the combustible gas content causes the
instrument to latch in the OVER-RANGE alarm condition.
Silicone compound vapors may affect the combustible
gas sensor and cause readings of combustible gas to be
lower than actual gas concentrations. If the instrument has
been used in an area where silicone vapors were present,
always calibrate the instrument before next use to ensure
accurate measurements.
Sensor openings and water barriers must be kept clean.
Obstruction of the sensor openings and/or contamination
of the water barriers may cause readings to be lower than
actual gas concentrations.
Sudden changes in atmospheric pressure may cause
temporary fluctuations in the oxygen reading.
Recharge battery only in a non-hazardous location.
Use the RS-232 port only in a non-hazardous location.
Instrument is tested for intrinsic safety in explosive
gas/air (21% oxygen) mixtures only.
CAUTION: High Over-Range (+OR) combustible
gas readings may indicate an
explosive concentration of
combustible gas.
!
!
!
!
!
!
!
!
!
!
