Loading Roll Paper Loading Roll Paper
1
Slide the black paper stop off the end of
the spindle.
Note: To use paper with a 3-inch core, attach the
gray adapters to the paper stops at each end.
See your Printer Guide for details.
2
Position the roll as shown, then slide it onto
the spindle.
3
Slide the black paper stop back onto the spindle and
insert it firmly into the end of the roll.
4
Open the roll paper cover.
5
Place the roll paper in the printer as shown. (The
black end of the spindle goes on the left.)
6
Make sure the printer is turned on, then press the
Paper Source button until the or icon
appears.
1
7
Release the paper lever.
8
Feed the paper into the slot and pull it all the way
through.
9
Turn the roll back to remove any slack. Then align
the bottom edge with the horizontal line and the
right edge with the vertical line.
10
Return the paper lever to the locked position. Then
close the roll paper cover.
11
Press the Pause button. The paper feeds into
printing position.
Caution: To prevent creasing the paper, remove it
from the paper path and roll it up when you’re not
printing.
