EM78612
Universal Serial Bus Microcontroller
34 •
•••
Product Specification(V1.0) 03.22.2006
(This specification is subject to change without further notice)
INSTRUCTION BINARY
HEX
MNEMONIC
OPERATION
STATUS AFFECTED
1 1010 kkkk kkkk
1Akk
AND A,k
A & k
→
A
Z
1 1011 kkkk kkkk
1Bkk
XOR A,k
A
⊕
k
→
A
Z
1 1100 kkkk kkkk
1Ckk
RETL k
k
→
A, [Top of Stack]
→
PC
None
1 1101 kkkk kkkk
1Dkk
SUB A,k
k-A
→
A
Z,C,DC
1 1111 kkkk kkkk
1Fkk
ADD A,k
k+A
→
A
Z,C,DC
Note
1 This instruction is applicable to IOCx only.
2 This instruction is not recommended for RE, RF operation.
C. Code Option Register
